Technical data
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
D-5
Mains buffering time
(longer power failures lead to
shutdown of the relay outputs
(monostable))
•SIMOCODE pro C -
24 V DC
110 V - 240 V AC/DC
•SIMOCODE pro V -
24 V DC
•SIMOCODE pro V -
110 V - 240 V AC/DC
Type 50 ms
Type 50 ms
Type 200 ms
Relay outputs:
•Number 3 monostable relay outputs
•Function Isolated NO contacts (NO contact response parameterizable
via internal signal conditioning), 2 relay outputs with common
ground, one separate relay output, freely-assignable to control
functions (e.g. network, star or delta contactor or operating
state status information.)
•Mandatory short-circuit protection
for auxiliary contacts (relay
outputs)
•Fuse links, operating class gL/gG 6 A, quick-response 10 A
(IEC 60947-5-1)
•Miniature circuit breaker 1.6 A, C-characteristic
(IEC 60947-5-1)
•Miniature circuit breaker 6 A, C-characteristic (I
k
< 500 A)
•Rated uninterrupted current 5 A
6 A at max. +50 °C
•Rated switching capacity AC-15 6 A/24 V AC 6 A/120 V AC 3 A / 230 V AC
DC-13 2 A/24 V DC 0.55 A/60 V DC 0.25 A/125 V DC
Inputs (binary) 4 inputs with a common ground that are supplied via the device
electronics (24 V DC) for measuring process signals (e.g. local
control station, key-operated switch, limit switch, etc.), freely-
assignable to control functions.
•24 V DC
Cable lengths (single)
Input characteristic
300 m
Type 1 according to EN 61131-2
Thermistor motor protection
(PTC binary)
•Total cold resistance <
1.5 kOhm
•Response value 3.4 kOhm - 3.8 kOhm
•Return value 1.5 kOhm - 1.65 kOhm
•Cable lengths Cross section: 2.5 mm
2
1.5 m m
2
0.5 mm
2
Length: 2 x 250 m
2 x 150 m
2 x 50 m
