Siemens SIMOCODE pro System Manual

Technical data
SIMOCODE pro
D-8 GWA 4NEB 631 6050-22 DS 03
1) for 3UF7103 and 3UF7104 up to 1000 V
2) for 3UF7103 and 3UF7104 up to 8 kV
3) More information can be found at http://www.siemens.com/simocode and D.7 "Short-
circuit protection with fuses for motor feeders for short-circuit currents up to 100 kA and
690 V" on Page D-24.
4) Screw connection is possible with an appropriate 3RT19... box terminal.
5) When connecting cable lugs complying with DIN 46235 to cables with a cross section
larger than 95 mm
2
, the 3RT19 56-4EA1 terminal cover is required to maintain phase
separation.
6) When connecting cable lugs complying with DIN 46234 to cables with a cross section
larger than 240 mm
2
and when connecting cable lugs complying with DIN 46235 to cables
with a cross section larger than 185 mm
2
, the 3RT19 56-4EA1 terminal cover
is required to maintain phase separation.
Table D-3: Technical data of the current measuring modules or current/voltage measuring modules
Notes on voltage measuring:
Current/voltage measuring modules
must be used with a decoupling
module for certain network types.
See table 1-35 in Chapter 1.7.6
"Decoupling module (DCM) for
current/voltage measuring modules,
SIMOCODE pro V device series.".
Caution
Note that the supply cables for voltage measurement may
require additional cable protection.
Through-hole opening Diameter
•Set current 0.3 A - 3 A;
2.4 A - 25 A
7. 5 m m
•Set current 10 A - 100 A 14.0 mm
•Set current 20 A - 200 A 25.0 mm
Bus connection
4)
•Set current I
s
20 A - 200 A 63 A - 630 A
•Connection screw M8x25 M10x30
•Tightening torque 10 Nm - 14 Nm 14 Nm - 24 Nm
•Solid with cable lug 16 mm
2
- 95 mm
2 4)5)
50 mm
2
- 240 mm
2 4)6)
•Stranded with cable lug 25 mm
2
- 120 mm
2 4)5)
70 mm
2
- 240 mm
2 4)6)
•AWG cable 6 kcmil - 300 kcmil 1/0 kcmil - 500 kcmil
Connection for voltage measurement
•Tightening torque TORQUE: 7 LB.IN - 10.3 LB.IN
0.8 Nm - 1.2 Nm
•Connection cross sections:
- Solid 2x 0.5 mm
2
- 2.5 mm
2
/ 1x 0.5 mm
2
- 4 mm
2
2 x AWG 20 to 14/1 x AWG 20 to 12
- Finely stranded, with end sleeve 2x 0.5 mm
2
- 1.5 mm
2
/ 1x 0.5 mm
2
- 2.5 mm
2
2 x AWG 20 to 16/1 x AWG 20 to 14

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
