Siemens SIMOCODE pro System Manual

Technical data
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
D-13
Table D-6: Technical data of the digital modules DM-F Local and DM-F PROFIsafe
•Rated uninterrupted cur-
rent of relay enabling
circuits
5A
•
Rated switching
capacity of relay
enabling circuits
AC-15: 3 A / AC 24 V; 3 A / AC 120 V; 1,5 A / AC 230 V
DC-13: 4 A / DC 24 V; 0,55 A / DC 60 V; 0,22 A / DC 125 V; 0,11 A / DC 250 V
• Electrical service life of
relay enabling circuits
0.1 million switching cycles (AC-15, 240 V/ 2 A)
•
Switching rate of the
relay enabling circuits
2000/h
Connection Removable terminal block with screw connection
• Tightening torque Torque: 7 lb.in to 10.3 lb.in
0.8 Nm to 1.2 Nm
• Connection cross-sec-
tions
:
-
solid 2x 0.5 mm
2
... 2.5 mm
2
/ 1x 0.5 mm
2
... 4 mm
2
2xAWG20to14/1xAWG20to12
-
Finely stranded with
end sleeve
2x 0.5 mm
2
... 1.5 mm
2
/ 1x 0.5 mm
2
... 2.5 mm
2
2xAWG20to16/1xAWG20to14

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
