Siemens SIMOCODE pro System Manual

Technical data
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
D-15
Flickering
yellow
Configuration fault
"2" OFF NC contact/NO contact
Yellow NC contact/NC contact
Flashing
yellow
Configuration mode awaits confirmation
Flickering
yellow
Configuration fault
"3" OFF 2 x 1-channel
Yellow 1 x 2-channel
Flashing
yellow
Configuration mode awaits confirmation
Flickering
yellow
Configuration fault
"4" OFF Delay time Y12, Y22, Y34 ∼ 50 ms
Yellow Delay time Y12, Y22, Y34 ∼ 10 ms
Flashing
yellow
Configuration mode awaits confirmation
Flickering
yellow
Configuration fault
"5" OFF Sensor circuit, automatic start
Yellow Sensor circuit, monitored start
Flashing
yellow
Configuration mode awaits confirmation
Flickering
yellow
Configuration fault
"6" OFF Cascade input 1, automatic start
Yellow Cascade input 1, monitored start
Flashing
yellow
Configuration mode awaits confirmation
Flickering
yellow
Configuration fault
"7" OFF With start-up testing

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
