3
05.01
3.5 Overview, position sensing
3-73
Siemens AG 2001 All rights reserved
SIMODRIVE 611 Planning Guide (PJU) 05.01 Edition
Table 3-5 Direct position sensing, digital controls
Control
board
version
Direct position sensing, digital controls
M: max. possible
measuring steps
G: Encoder system
accuracy
V: Multiplication
Z: Pulse number
Drive
control
SIMODRIVE
drive
module
Positioning with NC
n*
1FT6
Linear
2)
measuring
system,
incremental
SINUMERIK
with digital
coupling
(digital)
l 50 m
l 50 m
Voltage signals
1FK6
M = 2048 per
encoder signal
period and grid
division
G is dependent on
the accuracy of the
optional encoder
system.
Perfor
mance
Digital
FD and
MSD with
addi
tional
input
voltage
signal
SIMODRIVE
drive
module
Positioning with NC
n*
1FT6
Linear
2)
measuring
system,
incremental
SINUMERIK
with digital
coupling
(digital)
SVE
Current signals
l 50 m
l 50 m
l 18 m
Voltage signals
1FK6
M = 2048 per
encoder signal
period and grid
division
G is dependent on
the accuracy of the
optional encoder
system.
SIMODRIVE
drive
module
Positioning with NC
n*
1FT6
Linear measuring
system, incremen-
tal and absolute
SINUMERIK
with digital
coupling
(digital)
Data
Clock
l 50 m
l 50 m
Voltage signals
and EnDat interface
1FK6
M = 2048 per
encoder signal period
and grid division
G is dependent on
the accuracy of
the optional
encoder system.
Spindle positioning with the NC
Numerical
control
SIMODRIVE
drive
module
(digital)
n*
1PH4/6/7
Incremental
Rotary measuring
system, incremental
l 50 m
l 50 m
M = 2048 Z
per 360 degrees
mech.
Z...Pulse number
V = 2048
G is dependent on
the accuracy of the
optional encoder
system.
1) The absolute accuracy when synchronizing with a BERO is a function of:
the BERO switching time
BERO hysteresis
signal edge gradient of the BERO signal (dependent on the direction of rotation!) and the switching thresholds
in the drive; high >13 V, low < 5 V
the search speed or the signal run times in the evaluation electronics
2) Distancecoded reference marks can be evaluated
