Siemens SINAMICS S120 - Page 259

Line Modules Booksize
4.8 Basic Line Modules with cold plate
Booksize Power Units
Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
259
6SL3136-
1TE22-0AA0
1TE24-0AA0
1TE31-0AA0
Rated input currents
at AC 380 V
at AC 480 V / AC 528 V
at 480 V; S6 duty (40 %)
Peak current
at AC 400 V / AC 480 V)
A
AC
A
AC
A
AC
A
AC
34.5
31 / 29
38
113 / 91
69
62 / 58
78
208 / 172
172
154 / 145
193
265 / 252
DC link currents
Rated DC link current:
for 600 V
DC link current:
for 540 V
for 600 V DC; S6 duty (40 %)
for 600 V DC; peak current
A
DC
A
DC
A
DC
A
DC
33.5
37
43
100
67
48
87
200
167
185
217
292
Current carrying capacity
DC link busbars
Reinforced DC link busbars
24 V DC busbars
A
ACrms
A
ACrms
A
ACrms
100
150
20
200
--
20
200
--
20
Electronics current drawn
at 24 V DC
A
DC
0.9
1.1
1.6
Total power loss
(including electronics losses, see Power
loss tables (Page 756))
W 141.6 276.4 618.4
DC link capacitance
Basic Line Module
Drive line-up, max.
μF
μF
940
20000
1880
20000
4100
20000
Power factor
3)
cos φ Approx. 0.98
Circuit breaker
(IEC 60947 and UL)
See Chapter Overcurrent protection using fuses and circuit
breakers (Page 51)
Rated short-circuit current
SCCR
4)
kA 65 65 65
Max. total cable length
5)
See Chapter Combination options, Line Modules with line
reactors and line filters (Page 135)
Max. permissible heat sink temperature
° C
70
70
70
Weight
kg
6.4
10.9
16.4
1)
The specified power ratings apply to the line voltage range from 380 V to 480 V.
2)
Default for 400 V line systems; undervoltage trip threshold is adjusted to the parameterized rated voltage
3)
Only the fundamental component
4)
The resulting rated short-circuit current is obtained from the combination of the fuse or circuit breaker – and the Line
Module in the drive system.
5)
Maximum total cable length = Σ motor cables, line feeder cable from line filter to the Line Module
