Siemens SINAMICS S120

DC link components
8.6 Control Supply Module CSM
Booksize Power Units
534 Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
Table 8- 24 Installing the signaling contact
Signaling contact without terminal connector in
the delivery condition
Signaling contact, complete with terminal con-
nector
8.6.3.4
X24 24 V terminal adapter
Table 8- 25 X24 24 V terminal adapter
Terminal
Designation
Technical data
+
24 V power supply
Supply voltage 24 ... 28.8 V DC
M Ground Electronics ground
Type: Screw terminal 5 (Page 730)
The 24 V terminal adapter is included in the scope of supply.
