12.12 Power losses of the components
Booksize Power Units
758 Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
Unit
Power loss
Active Interface Modules
16 kW W 270
1)
36 kW
W
340
1)
55 kW W 380
1)
80 kW
W
490
1)
120 kW
W
585
1)
Line reactors for Active Line Modules
16 kW
W
170
36 kW
W
250
55 kW
W
350
80 kW
W
450
120 kW
W
590
Line reactors for Smart Line Modules
5 kW
W
62
10 kW
W
116
16 kW
W
110
36 kW
W
170
55 kW
W
200
Line reactors for Basic Line Modules
20 kW
W
130
40 kW W 270
100 kW
W
480
1)
Referred to U
DC link
= 600 V
12.12.4
Power loss for power units with internal air cooling
Table 12- 36 Overview of power loss at rated operation for power units with internal air cooling (includ-
ing electronics losses)
Unit
Power loss
Active Line Modules
16 kW W 282.8
36 kW
W
666
55 kW
W
945.6
80 kW
W
1383.6
120 kW
W
2243.2
Smart Line Modules Booksize
5 kW
W
79.2
10 kW
W
141.6
16 kW
W
187.8
36 kW
W
406
