Siemens SINAMICS S120 - Maximum Cable Lengths

Cabinet design and EMC Booksize
12.7 Connection systems
Booksize Power Units
716 Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
12.7.4
Maximum cable lengths
The table below provides an overview of the maximum permissible cable lengths for signal
and supply cables, power cables, and DC link cables.
Note
Total cable lengths for Line Modules
For data regarding maximum total cable lengths of Line Modules and general conditions for
maintaining the corresponding radio interference suppression category, see Chapter
Combination options of Line Modules with line reactors and line filters
(Page 135).
Table 12- 21 Maximum cable lengths
Type
Maximum length [m]
24 V DC power supply cables
30
1)
24 V signal cables
30
1)
DRIVE-CLiQ signal cables MC500 (RJ45)
100
DRIVE-CLiQ signal cables MC500 (M12)
30
DRIVE-CLiQ signal cables MC800PLUS (RJ45)
75
DRIVE-CLiQ signal cables MC800PLUS (M12)
30
DC link, including extensions
10
Power cable between line filter and line reactor
10 (shielded/unshielded)
2)
Power cable between line reactor and Line Module
10 (shielded/unshielded)
2)
Power cable between
motor and Motor Module up to I
n
= 9 A
50 (shielded)
75 (unshielded)
Power cable between
motor and Motor Module I
n
= 18 A
70 (shielded)
100 (unshielded)
Power cable between
motor and Motor Module I
n
≥ 30 A
100 (shielded)
150 (unshielded)
Power cable between Braking Module and braking resistor
10
1)
For longer lengths, users must connect suitable protective circuitry in order to provide surge voltage protection (refer to
Chapter "24 V DC supply/surge voltage protection").
2)
To comply with EMC limit values, shielded cables (preferably MOTION-CONNECT cables) must be used.
