Siemens SINAMICS S120

Cabinet design and EMC Booksize
12.12 Power losses of the components
Booksize Power Units
Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
757
Unit
Power loss
DC link components
Braking Module Booksize W 20
Braking Module Booksize Compact
W
< 40
Capacitor Module W 25
Control Supply Module
Line
DC link
W 70
65
12.12.3
Power loss for line filters and line reactors
Table 12- 35 Overview of power loss during rated operation for line filters and line reactors
Unit
Power loss
Basic Line Filters for Active Line Modules
16 kW
W
16
36 kW
W
26
55 kW
W
43
80 kW
W
56
120 kW
W
73
Basic Line Filter for Active Line Modules with Active Interface Module
16 kW
W
16
36 kW
W
26
55 kW
W
43
80 kW
W
56
120 kW
W
73
Wideband Line Filter for Active Line Modules
16 kW W 70
36 kW
W
90
55 kW
W
110
80 kW
W
150
120 kW
W
200
Basic Line Filter for Smart Line Modules
5 kW
W
5
10 kW
W
9
16 kW
W
16
36 kW
W
26
55 kW
W
43
Basic Line Filter for Basic Line Modules
20 kW
W
16
40 kW
W
26
100 kW
W
73
