Comparison of DRIVE-CLiQ signal cables
DRIVE-CLiQ signal cables are designed for various applications. The following table
provides an overview of the most important properties.
Table 12- 13 Properties of DRIVE-CLiQ signal cables
DRIVE-CLiQ signal cable
DRIVE-CLiQ
DRIVE-CLiQ
MOTION-CONNECT 500
DRIVE-CLiQ
MOTION-CONNECT 800PLUS
Approvals
cURus or UR/CSA
1)
In conformance with RoHS
Yes
Yes
Yes
Yes
Yes
Yes
Rated voltage V
0
/V in ac-
cordance with EN 50395
30 V 30 V 30 V
Test voltage, rms
500 V
500 V
500 V
Operating temperature at the surface
Permanently installed
Moveable
-20 … +80 °C
-
-20 … +80 °C
0 … 60 °C
-20 … +80 °C
-20 … +60 °C
Tensile load, max.
Permanently installed
Moveable
45 N/mm
2
_
80 N/mm
2
30 N/mm
2
50 N/mm
2
20 N/mm
2
Smallest bending radius
Permanently installed
Moveable
50 mm
-
35 mm
125 mm
35 mm
75 mm
Torsional stress
-
30 °/m absolute
30 °/m absolute
Bending operations
-
100000
10 million
Max. travel velocity
-
30 m/min
300 m/min
Max. acceleration
- 2 m/s
2
50 m/s
2
(3 m distance moved
through)
2)
insulation material
CFC/silicon-free CFC/silicon-free CFC/halogen/silicone-free
IEC 60754-1 / DIN VDE 0472-815
Oil resistance
EN 60811-2-1 EN 60811-2-1
(mineral oil only)
EN 60811-2-1
Protective jacket
PVC
Gray RAL 7032
PVC
DESINA color green
RAL 6018
PUR, HD22.10 S2
(VDE 0282, Part 10)
DESINA color green, RAL 6018
Flame retardant
EN 60332-1-1 to 1-3
EN 60332-1-1 to 1-3
EN 60332-1-1 to 1-3
1)
The UR/CSA file number is stamped on the cable sheath.
2)
Acceleration characteristics, refer below
