Shield connecting plates for power supply and motor cables
11.1.1
Description
Shield connection plates are available to connect the shields of line and motor power cables
as well as brake cables for all Line Modules, Motor Modules, and Active Interface Modules.
A shield connection terminal and/or clamp is used to connect the cable shield to the shield
connection plate. Shield supports must be properly arranged to ensure EMC compliance.
11.1.2
Shield connecting plates
Table 11- 1 Shield connection for components with internal air cooling
Component
Power
Total width of
component
Shield connection plate
Recommended shield connec-
tion
Line Module 5 kW / 10 kW 50 mm Included in the scope of deliv-
ery
16 kW 100 mm Included in the scope of deliv-
ery
KLBÜ CO4
1)
36 kW 150 mm 6SL3162-1AF00-0AA1 KLBÜ CO4
1)
55 kW
200 mm
6SL3162-1AH01-0AA0
Clamps
80 kW / 120 kW
300 mm
6SL3162-1AH00-0AA0
Clamps
Motor Module 3 … 18 A
2 x 3 A … 2 x 9 A
50 mm Integrated in the motor con-
nector
18 A (compact)
2 x 1.7 A ... 2 x 5 A
75 mm Integrated in the motor con-
nector
30 A and 2 x 18 A 100 mm Integrated in the motor plug
connector
45 A and 60 A 150 mm 6SL3162-1AF00-0AA1 KLBÜ CO1
1)
for the brake cable
KLBÜ CO4
1)
for the motor cable
85 A 200 mm 6SL3162-1AH01-0AA0 KLBÜ CO1
1)
for brake cable
clamps for motor cable
132 A and 200 A 300 mm 6SL3162-1AH00-0AA0 KLBÜ CO1
1)
for brake cable
clamps for motor cable
