Siemens SINAMICS S120 - Page 325

Line Modules Booksize
4.11 Smart Line Modules with cold plate
Booksize Power Units
Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
325
6SL3136-
6AE15-0AA.
6AE21-0AA.
Input currents
Rated input current
at AC 400 V
Input current
at AC 380 V / AC 480 V
at AC 400 V; S6 duty (40 %)
at AC 400 V; peak current
A
AC
A
AC
A
AC
A
AC
8.1
8.6 / 6.7
10.6
15.7
16.2
17 / 12.8
21.1
31.2
DC link currents
Rated DC link current
at 600 V
DC link current
at 540 V
at DC 600 V; S6 duty (40 %)
at DC 600 V; peak current
A
DC
A
DC
A
DC
A
DC
8.3
9.3
11
16.6
16.6
18.5
22
33.2
Current carrying capacity
DC link busbars
Reinforced DC link busbars
24 V DC busbars
A
DC
A
DC
A
DC
100
150
20
100
150
20
Electronics current drawn
at 24 V DC
A
DC
0.6
0.7
Power loss distribution
(incl. electronics losses)
internal
external
(see power loss tables (Page 756))
W
W
W
74.4
34.4
40
136.8
56.8
80
DC link capacitance
Smart Line Module
Drive line-up, max.
μF
μF
220
6000
330
6000
Power factor
cos φ
1
1
Circuit breaker
(IEC 60947 and UL)
See Chapter Overcurrent protection using fuses and
circuit breakers (Page 51)
Rated short-circuit current
SCCR
2)
kA 65 65
Max. total cable length
3)
See Chapter
Combination options, Line Modules with line
reactors and line filters (Page 135)
Max. permissible
heat-sink temperature
° C 60 65
Weight
kg
4.0
4.0
1)
The specified power ratings apply to the line voltage range from 380 V to 480 V.
2)
The resulting rated short-circuit current is obtained from the combination of the fuse or circuit breaker – and the Line
Module in the drive system.
3)
Maximum total cable length = Σ motor cables, line feeder cable from line filter to the Line Module
