Siemens SINAMICS S120 - Page 479

Motor Modules Booksize Compact
7.8 Technical data
Booksize Power Units
Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
479
Double Motor Modules Booksize Compact
6SL3420-
2TE11-7AA.
2TE13-0AA.
2TE15-0AA.
DC link current I
d rated
A
DC
4.1
7.2
12
DC-link voltage
(up to 2000 m above sea level)
V
DC
510 … 720
DC-link capacitance
μF
165
165
165
Overvoltage trip
Undervoltage trip
1)
V
DC
V
DC
820 ± 2 %
380 ± 2 %
Electronics power supply
V
DC
24 (20.4 … 28.8)
Electronics current consumption
at 24 VDC
For internal air cooling
For cold plate cooling
A
DC
A
DC
1.15
0.9
1.15
0.9
1.15
0.9
Current carrying capacity
DC-link busbars
Reinforced DC-link busbars
24 VDC busbars
A
A
A
100
150
20
100
150
20
100
150
20
Max. current motor brake
A
2 x 2
2 x 2
2 x 2
Unit rating
2)
Based on I
n
(600 V, 8 kHz)
Based on I
H
kW
kW
2 x 0.9
2 x 0.8
2 x 1.6
2 x 1.4
2 x 2.7
2 x 2.3
Total power loss
(including electronics losses, see Power loss ta-
bles (Page 756))
Internal air cooling
Cold plate int./ext.
W
W
114 (8 kHz)
42/72
134 (8 kHz)
44/90
194 (8 kHz)
59/135
Max. pulse frequency
without derating
with derating
kHz
kHz
8
16
Output frequency
Hz
0 … 550
Sound pressure level with internal air cooling
dB(A)
< 60
< 60
< 60
Cooling methods
Internal air cooling with mounted fan
Cold plate cooling
Cooling air requirement with internal air cooling
m
3
/h
29.6
29.6
29.6
Max. permissible heatsink temperature
For internal air cooling
For cold plate cooling
° C
° C
84
71
88
75
93
75
Ventilation clearances
above/below
mm
≥ 80
Weight
kg
3.4
3.4
3.4
1)
Default setting for 400 V line supplies, undervoltage trip threshold can be reduced by up to 80 V and is adjusted to the
parameterized line voltage
2)
Rated power of a typical standard induction motor at 400 V 3 AC
