Cabinet design and EMC Booksize
12.7 Connection systems
Booksize Power Units
Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
731
Screw terminal type
1_1 Connectable cable cross-
sections
Rigid, flexible
With end sleeve, without plastic sleeve
With end sleeve, with plastic sleeve
0.14 … 1.5 mm
2
0.25 … 1.5 mm
2
0.25 … 0.5 mm
2
Stripped length 7 mm
Tool
Screwdriver 0.4 x 2.5 mm
Tightening torque
0.22 … 0.25 Nm
2 Connectable cable cross-
sections
Rigid, flexible
With end sleeve, without plastic sleeve
With end sleeve, with plastic sleeve
AWG / kcmil
0.2 … 2.5 mm
2
0.2 … 2.5 mm
2
0.2 … 1.5 mm
2
22 … 12
Stripped length
6 … 7 mm
Tool
Screwdriver 0.5 x 3 mm
Tightening torque
0.4 … 0.5 Nm
3 Connectable cable cross-
sections
Flexible
With end sleeve, without plastic sleeve
With end sleeve, with plastic sleeve
0.2 … 2.5 mm
2
0.25 … 1 mm
2
0.25 … 1 mm
2
Stripped length
9 mm
Tool
Screwdriver 0.6 x 3.5 mm
Tightening torque
0.5 … 0.6 Nm
4 Connectable cable cross-
sections
Flexible
With end sleeve, without plastic sleeve
With end sleeve, with plastic sleeve
0.2 … 4 mm
2
0.25 … 4 mm
2
0.25 … 4 mm
2
Stripped length
7 mm
Tool
Screwdriver 0.6 x 3.5 mm
Tightening torque
0.5 … 0.6 Nm
5 Connectable cable cross-
sections
Flexible
With end sleeve, without plastic sleeve
With end sleeve, with plastic sleeve
0.5 … 6 mm
2
0.5 … 6 mm
2
0.5 … 6 mm
2
Stripped length
12 mm
Tool
Screwdriver 1.0 x 4.0 mm
Tightening torque
1.2 … 1.5 Nm
6 Connectable cable cross-
sections
Flexible
With end sleeve, without plastic sleeve
With end sleeve, with plastic sleeve
0.5 … 10 mm
2
0.5 … 10 mm
2
0.5 … 10 mm
2
Stripped length
11 mm
Tool
Screwdriver 1.0 x 4.0 mm
Tightening torque
1.5 … 1.8 Nm
7 Connectable cable cross-
sections
0.5 … 16 mm
2
Stripped length
14 mm
Tool
Screwdriver 1.0 x 4.0 mm
Tightening torque 1.5 … 1.7 Nm
