Description
Table 6-7 Rotation range of the power connector â‘  and encoder connector â‘¡
Motor Power connector â‘ ,
size M17 and M23
Encoder connector â‘¡,
size M17
Drawing
Size Angle α Angle α' Angle β Angle β'
SH45 M23 280° - 270° -


SH48
SH52
M17 225° 45° 225° 35°

Connecting
6.5î™ Connecting the motor
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
146 Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB
