• Scenario 1: A
drive password is con󹪝gured. The drive data in the backup 󹪝le were encrypted
using this password.
1 2 3
$SFBUFCBDLVQ꫼MF
3FTUPSFESJWFEBUB
0SJHJOBMMZDPO꫼HVSFEESJWFQBTTXPSE
$POWFSUFS"
$POWFSUFS"$POWFSUFS"
୫$IBOHFQBSBNFUFS
WBMVFT







– Click on "Restore".
A dialog to enter the password opens.
– Enter the drive password.
The drive data are loaded into the converter from the backup 󹪝le.
As a consequence, the status of the settings at the instant of the backup are restored.
Function "Drive data encryption" is activated. The drive password con󹪝gured in step 2 is
still e󹪜ective in the converter after data has been restored.
• Scenario 2: A drive password is con󹪝gured. The drive data in the backup 󹪝le were encrypted
using this password. Function "Drive data encryption" is deactivated after creating the
backup 󹪝le.
1 2 3
$SFBUFCBDLVQ꫼MF3FTUPSFESJWFEBUB
0SJHJOBMMZDPO꫼HVSFEESJWFQBTTXPSE
$POWFSUFS"
$POWFSUFS"$POWFSUFS"
୫$IBOHFQBSBNFUFS
WBMVFT
୫%FBDUJWBUF
FODSZQUJPO






– Click on "Restore".
A dialog to enter t
he password opens.
– Enter the drive password.
The drive data are loaded into the converter from the backup 󹪝le.
As a consequence, the status of the settings at the instant of the backup are restored.
Function "Drive data encryption" is activated. The originally con󹪝gured drive password is
applied.
Commissioning (web server)
7.4Functions and menus
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 205
