Control word 1 (STW1)
Control → Converter
Bit Drive function Explanation
Telegrams 102, 105 Telegrams 1, 2, 3,
5
Telegrams 102, 105 Telegrams 1, 2, 3,
5
14 1 = Torque control active
0 = Closed-loop speed
contr
ol active
Reser
ved Switch-over from speed to
torque control
--
15 Reserved
Status word 1 (ZSW1)
Converter → Control
Bit Status Explanation
Telegrams 102,
105
Telegrams 1, 2, 3, 5 Telegrams 102, 105 Telegrams 1, 2, 3, 5
00 1 = Ready for switching on Power supply switched on; electronics initialized;
pulses inhibit
ed.
01 1 = Ready for operation Motor is switched on (ON/OFF1=1), no fault is
active. Wit
h the command "Enable operation"
(STW1.3), the converter switches on the motor.
02 1 = Operation enabled Motor follows setpoint. See control word 1, bit 3.
03 1 = Fault present The converter has a fault. Acknowledge fault us‐
ing S
TW1.7.
04
1 = OFF2 inactive Coast down to standstill is not active.
05 1 = OFF3 inactive Quick stop is not active.
06 1 = "Switching on inhibited" active It is only possible to switch on the motor after an
OFF1 f
ollow
ed by ON.
07 1 = Alarm active Motor remains switched on; no acknowledge‐
ment is necessary
.
08 1 = Speed deviation within the tolerance
range
Se
tpoint / actual value deviation within the toler‐
ance range.
09 1 = Control requested The automation system has been requested to
take o
ver control of the converter.
10 1 = Comparison speed reached or exceeded Speed is greater than or equal to the correspond‐
ing maximum speed.
11
1
= Alarm
class bit 0
1 = Torque limit reached Internal diagnostics
for automation sys‐
tems with integrated
SINAMICS functionali‐
ty
Comparison value for
current or torque has
been reached or excee‐
ded.
12 1 = Alarm class bit 1 1 = Holding brake open Signal to open and close
a motor holding br
ake.
13 Reserved 0 = Alarm, motor over‐
temper
ature
-- Motor temperature
alarm threshold reached
Functions
10.4Communication telegrams
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
344 Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB
