Figure10-5 Extended ramp-function generator
Parameters
The f
ollo
wing lis
t includes the parameters of the "Ramp-function generator" function.
Number Name Unit
p1082[0] Maximum speed [rpm]
p1115 Ramp-function generator selection 
p1120[0] Ramp-function generator ramp-up time [s]
p1121[0] OFF1 ramp-down time [s]
p1130[0] Ramp-function generator initial r
ounding-o󹪜 time [s]
p1131[0]
R
amp-function generator 󹪝nal rounding-o󹪜 time [s]
p1135[0] OFF3 r
amp-down time [s]
Functions
10.5General functions
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
366 Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB
