25 X205 
40 X400 
41 X401 
42 X402 
50 X500 
51 X501 
52 X502 
53 X503 
54 X504 
55 X505 
56 X506 
57 X507 
Cause: The topology comparison has found a component in the actual topology which is not speci󹪝ed in t
he tar
get topology.
Alarm value (r2124, interpret hexadecimal):
ddccbbaa hex:
dd = component class (%2)
cc = connection number (%4)
bb = component class of the additional component (%1)
aa = component number (%3)
Note:
The component class of the additional component is contained in bb.
The component is described in dd, cc and aa, where the additional component is inserted.
Component class and connection number are described in F01375.
Remedy: Adapting topologies:
- Remove t
he additional component (correct the actual topology).
- Adapt the project/parameterizing in the commissioning tool (correct the target topology).
Note:
Under "Topology --> Topology view" the commissioning tool where relevant o󹪜ers improved diagnostics capability (e.g.
setpoint/actual value comparison).
A01420 Topology: Component di󹪜erent
Messag
e class: Error in the parameterization / con󹪝guration / commissioning pr
ocedure (18)
Message value: Component: %1, target: %2, actual: %3, di󹪜erence: %4
Component
: None
Response: NONE
System messages
12.3Faults and alarms
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
464 Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB
