Remedy: Adapting topologies:
- Change ov
er the actual topology to match the target topology.
- Load the target topology that matches the actual topology (commissioning tool).
Note:
Under "Topology --> Topology view" the commissioning tool where relevant oers improved diagnostics capability (e.g.
setpoint/actual value comparison).
F01451 Topology: Target topology is invalid
Message class: Error in the parameterization / conguration / commissioning pr
ocedure (18)
Message value: %1
Component: None
Response: NONE
Acknowledgment: IMMEDIATELY
Cause: An error was detected in the target topology.
The t
arg
et topology is invalid.
Fault value (r0949, interpret hexadecimal):
ccccbbaa hex: cccc = index error, bb = component number, aa = fault cause
aa = 1B hex = 27 dec: Error not specied.
aa = 1C hex = 28 dec: Value illegal.
aa = 1D hex = 29 dec: Incorrect ID.
aa = 1E hex = 30 dec: Incorrect ID length.
aa = 1F hex = 31 dec: Too few indices left.
aa = 20 hex = 32 dec: component is not connected to the converter.
Remedy: Download the target topology again using the commissioning tool.
A01481 Topology: Internal communications faulted
Message class: Error in the parameterization / conguration / commissioning pr
ocedure (18)
Message value: Component: %1, to %2, %3, connection: %4
Component: None
Response: NONE
System messages
12.3Faults and alarms
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 467
