Remedy: Adapting topologies:
- Connect the expect
ed component (correct the actual topology).
- Adapt the project/parameterizing in the commissioning tool (correct the target topology).
Note:
Under "Topology --> Topology view" the commissioning tool where relevant oers improved diagnostics capability (e.g.
setpoint/actual value comparison).
A01425 Topology: Serial number dierent
Messag
e class: Error in the parameterization / conguration / commissioning pr
ocedure (18)
Message value: Component: %1, %2, dierences: %3
Component
: None
Response: NONE
Acknowledgment: NONE
Explanation of the
mes
sag
e v
alue:
For %1
Component in target topology
Explanation of the
mes
sage v
alue:
For %2
Value Cause Remedy
0 Component unknown
1 Control Unit
2 Motor Module
3 Line Module
4 Sensor Module
5 Voltage Sensing Module
6 Terminal Module
7 DRIVE-CLiQ Hub Module
8 Controller Extension
9 Filter module
10 Hydraulic Module
49 DRIVE-CLiQ component
50 Option slot
60 Encoder
70 DRIVE-CLiQ motor
71 Hydraulic cylinder
72 Hydraulic valve
80 Motor
Cause: The topology comparison has detected dier
ences in
the actual and target topologies in relation to one component. The
serial number is dierent.
Alarm value (r2124, interpret hexadecimal):
ddccbbaa hex:
dd = reserved
cc = number of dierences (%3)
bb = component class (%2)
aa = component number (%1)
Note:
The component class is described in F01375.
The drive system is no longer booted. In this state, the drive control (closed-loop) cannot be enabled.
System messages
12.3Faults and alarms
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
466 Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB
