Cause: The topology comparison has detected a motor that is missing in the actual topology with respect to the target topology.
Alarm v
alue (r2124, interpr
et hexadecimal):
ddccbbaa hex:
dd = connection number (%4)
cc = component number (%3)
bb = component class (%2)
aa = component number of the component that has not been inserted (%1)
Note:
The component is described in dd, cc and bb, where the component has not been inserted.
Component class and connection number are described in F01375.
Remedy: Adapting topologies:
- Insert the com
ponents involved at the right connection (correct the actual topology).
- Adapt the project/parameterizing in the commissioning tool (correct the target topology).
Check the hardware:
- Check the 24 V supply voltage.
- Check cables for interruption and contact problems.
- Check that the component is working properly.
Note:
Under "Topology --> Topology view" the commissioning tool where relevant oers improved diagnostics capability (e.g.
setpoint/actual value comparison).
F01512 No scaling available
Message class: Error in the parameterization / conguration / commissioning pr
ocedure (18)
Message value: %1
Component: None
Response: OFF2
Acknowledgment: POWER ON
Cause: An attempt was made to determine a conversion factor for a scaling that does not exist.
F
ault value (r0949, int
erpret decimal):
Unit (e.g. corresponding to SPEED) for which an attempt was made to determine a factor.
Remedy: Apply scaling or check the transfer value.
A01514 Error when writing during a reconnect
Message class: Error in the parameterization / conguration / commissioning pr
ocedure (18)
Message value: Parameter: %1
Component: None
Response: NONE
Acknowledgment: NONE
System messages
12.3Faults and alarms
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 475
