Cause: Safety con󹪝guration is not pr
otected using UMAC (User Management and Access Control).
Remedy: Activate UMAC and assign the rights for changing the "Edit Safety Integrated application" safety con󹪝guration t
o a speci󹪝c
user that is saved with user name and password.
A01641 SI: Component exchange identi󹪝ed and save neces
sary
Message class: General drive fault (19)
Message value: Fault cause: %1
Variant: S200 PN
Component: Control Unit (CU)
Response: NONE
Acknowledgment: NONE
Explanation of the
mes
sage v
alue:
For %1

Bit Cause Remedy
0 It was identi󹪝ed that the dr
ive has been replaced 
4 It was identi󹪝ed that the Sensor Module has been
r
eplaced

5 It was identi󹪝ed that the sensor has been r
eplaced 
Cause: "Safety Integrated" has identi󹪝ed that a component has been r
eplaced.
No additional stop response is initiated, and therefore the operation of the speci󹪝c drive is not restricted.
When safety functions are active, after a component has been replaced it is necessary to carry out a partial acceptance test.
Alarm value (r2124, interpret binary).
Remedy: - Save all parameters (p0977 = 1 or retentively save).
- Ackno
wledge fault.
See also: r9776 (SI diagnostics)
F01646 SI: Change logbook
Message class: Safety monitoring channel has identi󹪝ed an error (10)
Mes
sage value: %1
Variant: S200 PN
Component: Control Unit (CU)
Response: OFF2
Acknowledgment: IMMEDIATELY
Cause: The saved functional safety checksum (r9780[0]) or hardware-related safety checksum (r9780[1]) di󹪜er
s fr
om the safety
checksum calculated when running up or a previously calculated safety checksum was not found.
An acceptance test is required as changes have been made to a safety parameter or the safety hardware.
Fault value (r0949, interpret decimal):
1: The safety logbook has identi󹪝ed that a functional safety checksum has changed. An acceptance test is required.
2: The safety logbook has identi󹪝ed that a hardware-related safety checksum has changed. An acceptance test is required.
Remedy: For fault value = 1:
- Carry out an accept
ance test and generate an acceptance report.
For fault value = 2:
- Carry out the function checks for the modi󹪝ed hardware and generate an acceptance report.
Note:
The procedure when carrying out an acceptance test as well as an example of the acceptance report are provided in the
following literature:
SINAMICS Function Manual Safety Integrated
C01649 SI: Internal software error
Message class: Hardware/software error (1)
System messages
12.3Faults and alarms
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 479
