Remedy: Correct parameters:
For xxxx = 10006 or 10022:
- Set a v
alid signal source in pxxxx.
C01682 SI: Monitoring function not supported
Message class: Error in the parameterization / con󹪝guration / commissioning pr
ocedure (18)
Message value: %1
Variant: S200 PN
Component: None
Response: OFF2
Acknowledgment: IMMEDIATELY
Cause: At least one of the monitoring functions enabled in p9604 is not supported with this 󹪝rm
war
e version on this device.
Note:
The message value (r60049, interpret binary) indicates the bits of the monitoring functions, which form this 󹪝rmware
version on this device, are not supported. If several, non-supported monitoring functions are simultaneously enabled, then
these are all displayed in the message value.
This message results in an STO (Safe Torque O󹪜).
See also: p9604 (SI enable)
Remedy: Correct parameter p9604 so that monitoring functions only permitted for this 󹪝rmwar
e version and for this device are
enabled.
See also: p9604 (SI enable)
C01690 SI: Data backup problem for the NVRAM
Message class: Hardware/software error (1)
Message value: %1
Variant: S200 PN
Component: Control Unit (CU)
Response: OFF2
Acknowledgment: POWER ON
Cause: When saving parameters r9780, r9781 and r9782 (Safety logbook) says, an error has occurred in conjunction with the
NVRAM.
No
te:
This fault does no
t result in a safety stop response.
Fault value (r60049, interpret decimal):
1: There is no physical NVRAM in the drive.
2: There is no longer any free memory space in the NVRAM.
Remedy: For fault value = 1:
- Replace the hardw
are.
For fault value = 2:
- De-select functions that are not required and that take up memory space in the NVRAM.
- Contact Technical Support.
Note:
NVRAM: Non-Volatile Random Access Memory (non-volatile read and write memory)
C01700 SI: STO (Safe Torque O󹪜) initiated
Messag
e class: Safety monitoring channel has identi󹪝ed an error (10)
Mes
sage value: -
Variant: S200 PN
Component: None
Response: OFF2
System messages
12.3Faults and alarms
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 483
