Cause: The macro cannot be executed.
Fault value (r0949, int
erpret hexadecimal):
ccccbbaa hex:
cccc = preliminary parameter number, bb = supplementary information, aa = fault cause
Fault causes for the trigger parameter itself:
19: Called 󹪝le is not valid for the trigger parameter.
20: Called 󹪝le is not valid for parameter 15.
21: Called 󹪝le is not valid for parameter 700.
22: Called 󹪝le is not valid for parameter 1000.
23: Called 󹪝le is not valid for parameter 1500.
24: Data type of a TAG is incorrect (e.g. Index, number or bit is not U16).
Fault causes for the parameters to be set:
25: Error level has an unde󹪝ned value.
26: Mode has an unde󹪝ned value.
27: A value was entered as string in the tag value that is not "DEFAULT".
31: Entered drive object type unknown.
32: A device was not able to be found for the determined drive object number.
34: A trigger parameter was recursively called.
35: It is not permissible to write to the parameter via macro.
36: Check, writing to a parameter unsuccessful, parameter can only be read, not available, incorrect data type, value range
or assignment incorrect.
37: Source parameter for a signal interconnection was not able to be determined.
38: An index was set for a non-indexed (or CDS-dependent) parameter.
39: No index was set for an indexed parameter.
41: A bit operation is only permissible for parameters with the parameter format DISPLAY_BIN.
42: A value not equal to 0 or 1 was set for a bit operation.
43: Reading the parameter to be changed by the bit operation was unsuccessful.
51: Factory setting for DEVICE may only be executed on the DEVICE.
61: The setting of a value was unsuccessful.
Remedy: - Check the parameter involved.
- Check the macr
o 󹪝le and signal interconnection.
F07083 Template: ACX 󹪝le not found
Mes
sage class: Error in the parameterization / con󹪝guration / commissioning pr
ocedure (18)
Message value: Parameter: %1
Component: None
Response: NONE
Acknowledgment: IMMEDIATELY
Cause: The template to be executed was not able to be found.
F
ault value (r0949, int
erpret decimal):
Parameter number with which the execution was started.
Remedy: - Check whether the corresponding template number is available.
F07084 Macro: Condition for WaitUntil not ful󹪝lled
Message class: Error in the parameterization / con󹪝guration / commissioning pr
ocedure (18)
Message value: Parameter: %1
Component: None
Response: NONE
Acknowledgment: IMMEDIATELY
