A30034 Power unit: Internal overtemperature
Message class: Power electronics faulted (5)
Message value: %1
Component: Power Unit
Response: NONE
Acknowledgment: NONE
Cause: The alarm threshold for internal overtemperature has been reached.
If t
he tem
perature inside the power unit increases up to the fault threshold, then fault F30036 is triggered.
- Ambient temperature might be too high.
- Insu󹪟cient cooling, fan failure.
Alarm value (r2124, interpret binary):
Bit 0 = 1: Overtemperature in the control electronics area.
Bit 1 = 1: Overtemperature in the power electronics area.
Bit 2 = 1: Overtemperature in the processor area.
Bit 3 = 1: Overtemperature in the processor area.
Bit 4 = 1: Overtemperature when the internal fan is defective.
Bit 5 = 1: Intake air overtemperature.
Remedy: - Check the ambient temperature.
- Check the fan f
or the inside of the unit.
F30036 Power unit: Internal overtemperature
Message class: Power electronics faulted (5)
Message value: %1
Component: Power Unit
Response: OFF2
Acknowledgment: IMMEDIATELY
Cause: The temperature inside the converter has exceeded the permissible limit value.
- Insu󹪟cient cooling, fan failur
e.
- Over
load.
- Ambient temperature too high.
Fault value (r0949, interpret binary):
Bit 0 = 1: Overtemperature in the control electronics area.
Bit 1 = 1: Overtemperature in the power electronics area.
Bit 2 = 1: Overtemperature in the processor area.
Bit 3 = 1: Overtemperature in the processor area.
Bit 4 = 1: Overtemperature when the internal fan is defective.
Bit 5 = 1: Intake air overtemperature.
Remedy: - Check the internal fan.
- Check the fan elements.
- Chec
k whether the ambient temperature is in the permissible range.
Notice:
This fault can only be acknowledged once the permissible temperature limit minus 5 K has been fallen below.
F30037 Power unit: Recti󹪝er ov
ertemperature
Message class: Power electronics faulted (5)
Message value: %1
Component: Power Unit
Response: OFF2
Acknowledgment: IMMEDIATELY
