Article No. 6SL5510-1BE 10-8AF0 11-0AF0
Fuse according to IEC 3NA3803 (10A)
3NW6303-1 (10 A)
3NA3803 (10A)
3NW6303-1 (10 A)
Fuse according to UL, ClassJ 10A 10A
Leakage current (mA) 39 39
Outline dimensions (W x H x D, mm) 60 x 180 x 200 60 x 180 x 200
Weight (g) 1912.4 1912.4
Table 14-8 Speci󹪝c technical dat
a of the 400 V converters frame size C
Article No. 6SL5510-1BE 11-5AF0 12-5AF0
Frame size FSC FSC
Rated input current (A) 5.5 8.0
Rated output current (A) 5.3 7.8
Maximum output current (A) 20 26.5
Maximum supported motor power (kW) 1.75 2.5
Power loss (W) 84 123
Inrush current (A) 15 15
Fuse according to IEC 3NA3805 (16A)
3NW6006-1 (12 A)
3NA3805 (16A)
3NW6305-1 (16 A)
Fuse according to UL, ClassJ 15A 20A
Leakage current (mA) 46 46
Outline dimensions (W x H x D, mm) 70 x 180 x 200 70 x 180 x 200
Weight (g) 2008.4 2008.4
Table 14-9 Speci󹪝c t
ec
hnical dat
a of the 400 V converters frame size D
Article No. 6SL5510-1BE 13-5AF0 15-0AF0 17-0AF0
Frame size FSD FSD FSD
Rated input current (A) 11.0 13.0 14.2
Rated output current (A) 11.0 12.6 13.2
Maximum output current (A) 38.1 38.8 37.4
Maximum supported motor power (kW) 3.5 5.0 7.0
Power loss (W) 171 194 205
Inrush current (A) 3 3 3
Fuse according to IEC 3NA3807 (20A)
3NW6307-1 (20 A)
3NA3807 (20A)
3NW6007-1 (20 A)
3NA3810 (25A)
3NW6010-1 (25 A)
Fuse according to UL, ClassJ 25A 25A 25A
Leakage current (mA) 60 60 60
Outline dimensions (W x H x D, mm) 95 x 260 x 230 95 x 260 x 230 95 x 260 x 230
Weight (g) 4517.5 4517.5 4517.5
Technical data
14.1Technical data of the converter
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 615
