Article No. 6SL5☐10-1BB 10-8AF0 11-0AF0
Fuse according to IEC 3NA3805 (16A)
3NW6006-1 (12 A)
3NA3805 (16A)
3NW6006-1 (12 A)
Fuse according to UL, ClassJ 15A 15A
Leakage current (mA) 1 AC 20 20
3 AC 23 23
Outline dimensions (W x H x D, mm) 60 x 170 x 195 60 x 170 x 195
Weight (g) S200 PN 1741.4 1741.4
S200 Basic PN 1741.4 1741.4
14.1.4 Speci󹪝c data of the 400 V converters
Technical data
Table 14-6 Speci󹪝c technical data of the 400 V converters frame size A
Article No. 6SL5510-1BE 10-2AF0 10-4AF0
Frame size FSA FSA
Rated input current (A) 1.3 1.3
Rated output current (A) 1.3 1.3
Maximum output current (A) 5.1 6.0
Maximum supported motor power (kW) 0.2 0.4
Power loss (W) 31 32
Inrush current (A) 7.5 7.5
Fuse according to IEC 3NA3804 (4A)
3NW6304-1 (4 A)
3NA3804 (4A)
3NW6304-1 (4 A)
Fuse according to UL, ClassJ 3 A 3 A
Leakage current (mA) 36 36
Outline dimensions (W x H x D, mm) 50 x 180 x 200 50 x 180 x 200
Weight (g) 1517.5 1517.5
Table 14-7 Speci󹪝c technical dat
a of the 400 V converters frame size B
Article No. 6SL5510-1BE 10-8AF0 11-0AF0
Frame size FSB FSB
Rated input current (A) 2.5 3.0
Rated output current (A) 2.5 3.0
Maximum output current (A) 9.3 11.5
Maximum supported motor power (kW) 0.75 1.0
Power loss (W) 46 54
Inrush current (A) 7.5 7.5
Technical data
14.1Technical data of the converter
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
614 Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB
