Article No. 6SL5☐10-1BB 10-1AF0 10-2AF0
Inrush current (A) 10.5 10.5
Fuse according to IEC 3NA3804 (4A)
3NW6304-1 (4 A)
3NA3804 (4A)
3NW6304-1 (4 A)
Fuse according to UL, ClassJ 3 A 3 A
Leakage current (mA) 1 AC 19 19
3 AC 24 24
Outline dimensions (W x H x D, mm) 40 x 170 x 135 40 x 170 x 135
Weight (g) S200 PN 763 809.6
S200 Basic PN 763 763
Table 14-4 Speci󹪝c technical dat
a of the 200 V converters frame size B
Article No. 6SL5☐10-1BB 10-4AF0
Frame size FSB
Rated input current (A) 1 AC 3.0
3 AC 1.8
Rated output current (A) 2.4
Maximum output current (A) 9.2
Maximum supported motor power (kW) 0.4
Power loss (W) 24
Inrush current (A) 8.5
Fuse according to IEC 3NA3801 (6A)
3NW6301-1 (6 A)
Fuse according to UL, ClassJ 6 A
Leakage current (mA) 1 AC 21
3 AC 24
Outline dimensions (W x H x D, mm) 40 x 170 x 170
Weight (g) S200 PN 1028.9
S200 Basic PN 960
Table 14-5 Speci󹪝c technical dat
a of the 200 V converters frame size C
Article No. 6SL5☐10-1BB 10-8AF0 11-0AF0
Frame size FSC FSC
Rated input current (A) 1 AC 7.0 8.0
3 AC 3.5 4.0
Rated output current (A) 4.4 4.4
Maximum output current (A) 16.8 16.8
Maximum supported motor power (kW) 0.75 1.0
Power loss (W) 45 46
Inrush current (A) 7.6 7.6
Technical data
14.1Technical data of the converter
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 613
