Parameter Description
STO fullls t
he req
uirements of the following standards:
• SIL3 according to IEC61800-5-2
• PLe according to ISO13849-1
• Category 4 according to ISO13849‑1
Response time: ≤ 20 ms
The response time of the Saf
e Torque O function is the time between
selecting the function and the function becoming active.
Probability of Failure per Hour (PFH): < 10
-7
Failure
probabilities must be specied for Safety Integrated Functions in the
form of a PFH value according to IEC61800-5-2, IEC62061 and
EN ISO 13849-1. The PFH value of a Safety Integrated Function depends on
the safety concept of the converter, its hardware conguration and the PFH
values of the other components used for the Safety Integrated Function.
Mission time: 20 years
You ma
y not operate converters with integrated safety functions for longer
than the mission time. The mission time starts when the device is delivered.
The mission time cannot be extended. This is the case even if a service
department checks the converter – or in the meantime, the converter was
decommissioned.
1)
Int
eg
r
al solid state short circuit protection does not provide branch circuit protection. Branch circuit protection must be
provided in accordance with the National Electrical Code and any additional local codes.
2)
The 200 V converter has an overvoltage threshold of 410VDC and an undervoltage threshold of 155 V DC; the 400 V
converter has an overvoltage threshold of 820VDC and undervoltage threshold of 320VDC.
3)
Motor temperature is calculated by motor thermal model and protected by the output current from the converter.
4)
To comply with permissible line harmonics, depending on the line connection conditions, dierent values may be required.
5)
The maximum permissible short-circuit current for 200 V variants with Type E Combination Motor Controllers is 65kA.
6)
When the converter works with a motor with a brake, the voltage tolerance of 24 V DC power supply must be -5% to +20%
to meet the voltage requirement of the brake.
14.1.3 Specic data of the 200 V converters
Technical data
Table 14-3 Specic technical data of the 200 V converters frame size A
Article No. 6SL5☐10-1BB 10-1AF0 10-2AF0
Frame size FSA FSA
Rated input current (A) 1 AC 1.2 2.0
3 AC 0.6 1.1
Rated output current (A) 0.81 1.33
Maximum output current (A) 3.3 5.1
Maximum supported motor power (kW) 0.1 0.2
Power loss (W) 12 15
Technical data
14.1Technical data of the converter
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
612 Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB
