Parameter Description
Cooling type
• For 200 V variants: Natural cooling
•
For 400 V v
ariants:
– FSA and FSB: Natural cooling
– FSC and FSD: Fan cooling
Degree of protection according to IEC60529 IP20
Mains supply
Permissible mains supply network TN, TT, IT
Line voltage 1 AC/3 AC200 V...240 V
3 A
C 380 V ... 480 V
Line freq
uency (Hz) 50/60
Permissible line voltage 󹪞uctuation -15% ... +10%
Permissible line frequency 󹪞uctuation -10% ... +10%
24 V DC power supply
Voltage (V) 24 (-15% ... +20%)
6)
Permissible voltage 󹪞uctuation (V) When using a motor without brake: 20.4 ... 28.8
When using a mo
tor wit
h brake: 22.8 ... 28.8
Maximum current (A)
• For 200 V variants:
– When using a mot
or without a brake: 1.2
– When using a motor with a brake: 2.2
• For 400 V variants:
– When using a motor without a brake: 1.2
– When using a motor with a brake: 3.2
Safety insulation class SELV
Inputs and outputs
Digital inputs
• Maximum input current: 4mA (for "1" signal: > 1.5 mA)
•
General delay time:
– DI 0 → 1: < 10 μs
– DI 1 → 0: < 150 μs
• Fast digital input delay time:
– F-DI 0 → 1: < 5 μs
– F-DI 1 → 0: < 5 μs
Digital outputs
• Maximum output current: 100mA
• Delay time: < 2ms
Pulse tr
ain output (for S200 PN only) Output voltage: line driver (5V di󹪜erential)
Output freq
uency: ≤ 4 MHz
Safety Integrated (for S200 PN only)
Safety function STO, SIL3/PLe/Category4
Technical data
14.1Technical data of the converter
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 611
