Property Description
Mechanical environmental conditions
• Shock:
–
Peak acceler
ation: 5g
– Duration of shock: 30ms
• Vibration:
– 10Hz...58Hz: 0.075mm deection
– 58Hz...200 Hz: 1g vibration
Shocks and vibrations permissible according to Class 3M1 to
IEC60721-3-3
Protection against chemical substances Protected according to Class 3C2 to IEC60721-3-3
Biological environmental conditions Suitable according to Class 3B1 to IEC60721-3-3
Pollution Suitable for environments with degree of pollution 2 according to
IEC61800-5-1
14.1.2 General technical data
Technical dat
a
Table 14-2 General technical data of the converter
Parameter Description
Overload capability 350% overload: for 200 V and 400 V variants with a power rating of 0.1 kW
to 0.75 kW
300% o
verload: for 200 V and 400 V variants with a power rating of 1 kW to
7 kW
Output frequency (Hz) 0 ... 550
IGBT pulse frequency without derating (kHz) 8
Control system Servo control
Dynamic brake Integrated
Protective functions Grounding fault protection, output short-circuit protection
1)
, o
ver
voltage/
undervoltage protection
2)
, converter I
2
t protection, motor overtemperature
protection
3)
, IGBT overtemperature protection
Surge voltage Fulll the requirement of the standard IEC61800-3
Over
voltage category Category III according to IEC 61800-5-1
Minimum prospective short‑circuit current To prevent r
e
in the event of a fault, a minimum value must be ensured for
the prospective short-circuit current so that the upstream protective device
trips quickly enough. A typical value when dimensioning is 20 to 25 times
4)
the rated current of the protection device used.
Maximum permissible short-circuit current
(SCCR, kA rms)
• For 200 V variants: 100
5)
• For 400 V v
ariants: 65
Technical data
14.1Technical data of the converter
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
610 Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB
