Property MOTION-CONNECT 350
power cable
MO
TION-CONNECT 350 en‐
coder cable
MOTION-CONNECT 350
brake cable
Minimum bending radius, dy‐
namic (mm)
7.5 x outer diameter 7.5 x outer diameter 7.5 x outer diameter
Maximum acceleration (m/s
2
) 3 3 3
Maximum traversing velocity
(m/min)
• 1FL2 0.4kW...2kW:40
•
1FL2 2.5kW:50
•
1FL2 3.5 kW...7kW:50
40 50
14.3.2 Technical data of MOTION-CONNECT 380
14.3.2.1 General t
echnical data
Technical data
Table 14-66 General technical data of MOTION-CONNECT 380
Property MOTION-CONNECT 380
po
wer cable
MO
TION-CONNECT 380 en‐
coder cable
MOTION-CONNECT 380
brake cable
Jacket material PUR PUR PUR
Number of conductors
• With brake conductors:6
•
Wit
hout brake conduc‐
tors:4
6 2
Operating temperature (°C) -20...+80 -20...+80 -20...+80
Shielding Braided shield;
co
ver
age ≥ 85%
Braided shield;
coverage ≥ 85%
Braided shield;
coverage ≥ 85%
Oil resistance EN60811-2-1 EN60811-2-1 EN60811-2-1
Flame retardancy EN60332-1-1 to 1-3 EN60332-1-1 to 1-3 EN60332-1-1 to 1-3
Coolant resistance EN60811-2-1 EN60811-2-1 EN60811-2-1
Degree of protection (motor-
side onl
y)
IP65 IP65 IP65
Bending cycles 5 million 5 million 5 million
R
ated voltage U
0
/U (V)
• 200V converters:
300/1000
•
400V conv
erters:
600/1000
30/300 30/300
Technical data
14.3Technical data of MOTION-CONNECT cables
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
682 Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB
