14.3.2.2 Speci󹪝c technical data
Technical data
Table 14-67 Cable used for 1FL2 low or medium inertia motors
Property MOTION-CONNECT 380
po
wer cable
MO
TION-CONNECT 380 en‐
coder cable
MOTION-CONNECT 380
brake cable
Cross-section of conductors
(mm
2
)
• With brake conductors:
4 x 0.75 + 2 x 0.38
(4 × 18 AWG + 2 × 22
A
WG)
• Without brake conduc‐
tors:
4 x 0.75
(4 × 18 AWG)
• Cable length up to 15m:
3 x 2 x 0.25
(3 × 2 × 24 AWG)
• Cable length 20m or
30m:
2 x 2 x 0.25 + 2 x 0.38
(2 × 2 × 24 AWG + 2 × 22
AWG)

-
Outer diameter (mm) ø (7.5 ± 0.2) ø (7 ± 0.2) -
Minimum bending radius, stat‐
ic (mm)
4 x outer diameter 4 x outer diameter -
Minimum bending radius, dy‐
namic (mm)
7.5 x outer diameter 7.5 x outer diameter -
Maximum acceleration (m/s
2
) 5 5 -
Maximum traversing velocity
(m/min)
180 180 -
Table 14-68 Cable used for 1FL2 high inertia motors
Property MOTION-CONNECT 380
power cable
MO
TION-CONNECT 380 en‐
coder cable
MOTION-CONNECT 380
brake cable
Cross-section of conductors
(mm
2
)
• 1FL2 0.4kW...2kW:
4 x 0.75
(4 × 18 AWG)
•
1FL2 2.5kW:4 x 1.5
(4 × 16 AWG)
• 1FL2 3.5 kW...7kW:
4 x 2.5
(4 × 14 AWG)
• Cable length up to 15m:
3 x 2 x 0.25
(3 × 2 × 24 AWG)
• Cable length 20m or
30m:
2 x 2 x 0.25 + 2 x 0.38
(2 × 2 × 24 AWG + 2 × 22
AWG)

2 x 0.75
(2 × 18 AWG)
Outer diameter (mm)
• 1FL2 0.4kW...2kW:
ø (7.5 ± 0.2)
• 1FL2 2.5kW:ø (9 ± 0.3)
•
1FL2 3.5 kW...7kW:
ø (10.5 ± 0.3)
ø (7 ± 0.2) ø (6 ± 0.3)
Minimum bending radius, stat‐
ic (mm)
4 x outer diameter 4 x outer diameter 4 x outer diameter
Technical data
14.3Technical data of MOTION-CONNECT cables
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 683
