r0044 Thermal converter utilization
Data type: FloatingPoint32 Visible in: S
tandard display
Read permission: Read drive data or acknowledge messages
Write permission: Edit device congur
ation or driv
e applications
Parameter group: Mode signals / displays, Power unit
Unit: %
Description: Displays the thermal converter utilization as a percentage.
With t
his value, various thermal monitoring functions are taken into account.
Dependency: See also: r0034
Note
The thermal mot
or utilization is displayed in parameter r0034.
r0046.0...30 Missing enable signals
Data type: Unsigned32 Visible in: S
tandard display
Read permission: Read drive data or acknowledge messages
Write permission: Edit device congur
ation or driv
e applications
Parameter group: Control/status words, Drive enable signals
Unit: -
Description: Displays the missing enable signals. All enable signals are required to operate the drive. The enable signals are set by
t
he contr
ol.
Bit arr
ay: Bit Signal name 1 signal 0 signal
00 OFF1 enable missing Yes No
01 OFF2 enable missing Yes No
02 OFF3 enable missing Yes No
03 Operation enable missing Yes No
08 Safety enable missing Yes No
10 Ramp-function generator enable missing Yes No
12 Speed setpoint enable missing Yes No
16 OFF1 enable internal missing Yes No
17 OFF2 enable internal missing Yes No
18 OFF3 enable internal missing Yes No
19 Pulse enable internal missing Yes No
21 STOP2 enable internal missing Yes No
26 Drive inactive or not operational Yes No
28 Brake open missing Yes No
30 Speed controller enable missing Yes No
Dependency: See also: r0002
Appendix
A.3Parameters
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
700 Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB
