Note
For index [0]:
This inde
x shows the actual state of the I2t monitoring on the AC side.
The reference value represents the AC current that the power unit can permanently provide, without the inuence of
switching losses (e.g. the continuously permissible current of capacitors, inductances, busbars, etc.).
For index [1]:
This index shows the actual state of the active power monitoring.
The reference value represents the active power that the power unit can continuously provide.
For index [2]:
This index shows the actual state of the I2t monitoring on the DC side.
The reference value represents the DC current that can continuously ow in the DC link.
r0037[0...10] Power unit temperatures
Data type: FloatingPoint32 Visible in: Ext
ended display
Read permission: Read drive data or acknowledge messages
Write permission: Edit device congur
ation or driv
e applications
Parameter group: Mode signals / displays, Power unit
Unit: °C
Description: Display for the temperatures in the power unit.
Index: [0] = Inverter maximum value
[1] = Depletion lay
er maximum value
[2] = Rectier maximum value
[3] = Air intake
[4] = Interior of power unit
[5] = Cooling unit liquid intake
[6] = Capacitor air discharge
[7] = Depletion layer maximum value 1
[8] = Depletion layer maximum value 2
[9] = Depletion layer maximum value 3
[10] = Depletion layer maximum value 4
Note
The value of -200 indicates t
hat there is no measuring signal.
r0037[0]: Maximum value of the inverter temperatures.
r0037[1]: Maximum value of the depletion layer temperatures.
In the case of a fault, the particular shutdown threshold depends on the power unit, and cannot be read out.
r0039[0...2] Energy display
Data type: FloatingPoint32 Visible in: S
tandard display
Read permission: Read drive data or acknowledge messages
Write permission: Edit device congur
ation or driv
e applications
Parameter group: Mode signals / displays, Power loss optimization
Unit: kWh
Description: Display for the energy values at the drive output terminals.
Index: [0] = Energy balance (sum)
[1] = Energy dra
wn
[2] = Energy fed back
Note
For index [0]:
Dier
ence between the energy drawn and energy that is fed back.
Appendix
A.3Parameters
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 699
