Siemens SINAMICS SIMOTICS S200 PROFINET User Manual

r0032 Active power actual value smoothed
 Data type: FloatingPoint32 Visible in: S
tandard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Mode signals / displays
Unit: kW
Description: Display for the smoothed actual value of the active power.
Dependency: See also: r0082
Note
The activ
e pow
er is available smoothed (r0032 with 100 ms, r0082[1] with 1 ms) and unsmoothed (r0082[0]).
r0034 Motor utilization thermal
 Data type: FloatingPoint32 Visible in: S
tandard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Motor temperature, Mode signals / displays
Unit: %
Description: Displays the thermal motor utilization taking into account the ambient temperature set in p0613.
Dependency: See also: p0613
See also: F07011, A07012
NOTICE
After the drive is switched on, the system starts to determine the motor temperature with an assumed model value. This
means that the v
alue for the motor utilization is only valid after a stabilization time.
r0036[0...2] Power unit overload
 Data type: FloatingPoint32 Visible in: Ext
ended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Mode signals / displays, Power unit
Unit: %
Description: Display when the power unit is overloaded.
A refer
ence value is de󹪝ned for the monitoring functions.
An overload (0 %) is not displayed if the reference value is not exceeded.
The display value increases if the reference value is exceeded.
An alarm is output if an overload is active over a certain time period; a fault is output when 100% is reached.
Index: [0] = I2t (AC)
[1] = Reserved
[2] = Reser
ved
Dependency: See also: p0290
See also: F30005, A30256, A30257, F30258, A30267, F30268
Appendix
A.3Parameters
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
698 Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB
