Note
The bu󹪜er paramet
ers are cyclically updated (states are indicated in r2139).
Fault bu󹪜er structure (general principle):
r0945[0], r0949[0] or r2133[0], r2130[0], r0948[0], r2136[0], r2109[0] --> fault 1 (oldest active fault) of the active
incident
. . .
r0945[7], r0949[7] or r2133[7], r2130[7], r0948[7], r2136[7], r2109[7] --> fault 8 (latest active fault) of the active
incident
For more than 8 active faults, only the entries are overwritten at the eighth position (index 7).
History of acknowledged faults:
If a fault incident is acknowledged, then all alarms of the 1st fault incident are transferred into the 2nd fault incident,
this becomes the 1st acknowledged fault incident.
The 2nd incident is transferred into the 3rd, the 3rd into the 4th etc. The last incident is rejected.
r0945[8], r0949[8] or r2133[8], r2130[0], r0948[8], r2136[8], r2109[8] --> fault 1 of the 1st acknowledged incident
. . .
r0945[16], r0949[16] or r2133[16], r2130[16], r0948[16], r2136[16], r2109[16] --> fault 1 of the 2nd acknowledged
incident
. . .
r0945[56], r0949[56] or r2133[56], r2130[56], r0948[56], r2136[56], r2109[56] --> fault 1 of the 7th acknowledged
incident
. . .
r0945[63], r0949[63] or r2133[63], r2130[63], r0948[63], r2136[63], r2109[63] --> fault 8 (oldest fault that has gone)
of the 7th acknowledged incident
r0948[0...63] Fault time received in milliseconds
 Data type: Unsigned32 Visible in: Ext
ended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Faults / alarms
Unit: ms
Description: Displays the system runtime in milliseconds when the fault occurred.
Dependency: See also: r0945, r0947, r0949, r2109, r2114, r2130, r2133, r2136, r3122
NOTICE
The time comprises r2130 (days) and r0948 (milliseconds).
Note
The bu󹪜er paramet
ers are cyclically updated in the background (refer to status signal in r2139).
The structure of the fault bu󹪜er and the assignment of the indices is shown in r0945.
When the parameter is read via PROFIdrive, the TimeDi󹪜erence data type applies.
r0949[0...63] Fault value
 Data type: Integer32 V
isible in: Extended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Faults / alarms
Unit: -
Description: Displays additional information about the fault that occurred (as integer number).
Dependency: See also: r0945, r0947, r0948, r2109, r2130, r2133, r2136, r3122
Note
The bu󹪜er par
amet
ers are cyclically updated in the background (refer to status signal in r2139).
The structure of the fault bu󹪜er and the assignment of the indices is shown in r0945.
