r1196 DSC position setpoint
 Data type: Integer32 V
isible in: Standard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Speed precontrol
Unit: -
Description: Display and numerical signal source of the position setpoint of DSC in 󹪝ne pulses.
Note
DSC: Dynamic Servo Contr
ol
p1215[0] Motor holding brake con󹪝guration
S200 Basic PN Data type: Int
eger16 Visible in: Standard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Ready for operation
Parameter group: Motor holding brake
 Unit: -
 Min:
0
Max:
3
Factory setting:
0
Description: Sets the con󹪝guration for t
he motor holding brake.
Value: 0: No motor holding brake available
 3: Motor holding brake like seq control, conn via interconnection
Dependency: See also: p1216, p1217, p1226, p1227, p1228
CAUTION
For the setting p1215 = 0, if a brake is used, it remains closed. If the motor moves, this will destroy the brake.
NOTICE
If p1215 was set to 3, then when the pulses are canceled, the brake is closed even if the motor is still rotating. Pulses
can be canceled as a result of an OFF2 or "Enable operation" via 󹪝eldbus or a fault wit
h OFF2 response.
Note
If an e
xternal motor holding brake is being used, then p1215 should be set to 3 and r0899.12 should be used as brake
control signal.
The parameter can only be set to zero when the pulses are inhibited.
p1215[0] Motor holding brake con󹪝guration
S200 PN Data type: Int
eger16 Visible in: Standard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Ready for operation
Parameter group: Motor holding brake
 Unit: -
 Min:
0
Max:
2
Factory setting:
0
Description: Sets the con󹪝guration for t
he motor holding brake.
For value 2:
This setting allows the motor shaft to be rotated for installation purposes.
Value: 0: No motor holding brake available
Appendix
A.3Parameters
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
736 Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB
