p1130[0] Ramp-function generator initial rounding-o time
Data type: FloatingP
oint32 Visible in: Extended display
Read permission: Read drive data or acknowledge messages
Write permission: Edit device congur
ation or driv
e applications
Can be changed in the operating
stat
e:
Operation
Parameter group: Ramp-function generator
Unit: s
Min:
0.000 [s]
Max:
30.000 [s]
Factory setting:
0.000 [s]
Description: Sets the initial rounding-o time for t
he extended ramp-function generator.
The value applies to ramp-up and ramp-down.
Note
Rounding-o times avoid an abrup
t response and prevent damage to the mechanical system.
p1131[0] Ramp-function generator nal rounding-o time
Data type: FloatingP
oint32 Visible in: Extended display
Read permission: Read drive data or acknowledge messages
Write permission: Edit device congur
ation or driv
e applications
Can be changed in the operating
stat
e:
Operation
Parameter group: Ramp-function generator
Unit: s
Min:
0.000 [s]
Max:
30.000 [s]
Factory setting:
0.000 [s]
Description: Sets the nal rounding-o time for t
he extended ramp generator.
The value applies to ramp-up and ramp-down.
Note
Rounding-o times avoid an abrup
t response and prevent damage to the mechanical system.
p1135[0] OFF3 ramp-down time
Data type: FloatingPoint32 Visible in: S
tandard display
Read permission: Read drive data or acknowledge messages
Write permission: Edit device congur
ation or driv
e applications
Can be changed in the operating
stat
e:
Operation
Parameter group: Ramp-function generator, Shutdown functions, Setpoint addition, Quick
commissioning
Unit
: s
Min:
0.000 [s]
Max:
600.000 [s]
Factory setting:
0.000 [s]
Description: Sets the ramp-down time from the maximum speed down to zero speed for the OFF3 command.
Note
This time can be exceeded if t
he DC link voltage reaches its maximum value.
Appendix
A.3Parameters
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 735
