p1115 Ramp-function generator selection
 Data type: Integer16 V
isible in: Extended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Ready for operation
Parameter group: Ramp-function generator
 Unit: -
 Min:
0
Max:
1
Factory setting:
0
Description: Sets the ramp-function generator type.
Value: 0: Basic ramp-function generator
 1: Extended ramp-function generator
Note
Ano
ther r
amp-function generator type can only be selected when the motor is at a standstill.
p1120[0] Ramp-function generator ramp-up time
 Data type: FloatingPoint32 Visible in: S
tandard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Operation
Parameter group: Ramp-function generator, Quick commissioning
 Unit: s
 Min:
0.000 [s]
Max:
999999.000 [s]
Factory setting:
10.000 [s]
Description: The ramp-function generator ramps-up the speed setpoint from standstill (setpoint = 0) up to the maximum speed
(p1082) in this time.
Dependency: See also: p1082
p1121[0]
OFF1 ramp-down time
 Data type: FloatingPoint32 Visible in: Standard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Operation
Parameter group: Quick commissioning
 Unit: s
 Min:
0.000 [s]
Max:
999999.000 [s]
Factory setting:
1.000 [s]
Description: Sets the ramp-down time after an OFF1 command.
The value is ref
erred to the maximum speed (p1082).
After an OFF1 command, within this time, the speed setpoint is ramped down from the maximum speed (p1082) to
standstill.
Dependency: See also: p1082
Appendix
A.3Parameters
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
734 Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB
