Note
Stands
till is detected if at least one of the following conditions is satis󹪝ed:
- The speed actual value falls below the speed threshold in p1226 and the time started after this in p1228 has expired.
- The speed setpoint falls below the speed threshold in p1226 and the time started after this in p1227 has expired.
For p1227 = 300.000 s the following applies:
Monitoring is deactivated.
For p1227 = 0.000 s, the following applies:
With OFF1 or OFF3 and a ramp-down time = 0, the pulses are immediately canceled and the motor "coasts" down.
p1228[0] Pulse cancellation delay time
 Data type: FloatingPoint32 Visible in: Ext
ended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Operation
Parameter group: Motor holding brake, Shutdown functions
 Unit: s
 Min:
0.000 [s]
Max:
299.000 [s]
Factory setting:
0.000 [s]
Description: Sets the delay time for pulse cancellation.
After OFF1 or OFF3, t
he pulses are canceled, if at least one of the following conditions is ful󹪝lled:
- The speed actual value falls below the threshold in p1226 and the time started after this in p1228 has expired.
- The speed setpoint falls below the threshold in p1226 and the time started after this in p1227 has expired.
Dependency: See also: p1226, p1227
NOTICE
When the motor holding brake is activated, pulse cancellation is additionally delayed by the brake closing time (p1217).
r1407.0...28 Status word speed controller
 Data type: Unsigned32 Visible in: Ext
ended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Torque setpoints, U/f control, Torque limiting, Speed actual value 󹪝lter,
Control/
status words, Acceleration model, Setpoint addition, Speed precontrol, Speed
setpoint 󹪝lter
Unit: -
Description: Displays the status word of the speed controller.
Bit array: Bit Signal name 1 signal 0 signal 
 00 Reserved Yes No 
 01 Reserved Yes No 
 02 Torque control active Yes No 
 04 Speed setpoint from DSC Yes No 
 05 Speed controller I component frozen Yes No 
 06 Speed controller I component set Yes No 
 07 Torque limit reached Yes No 
 08 Upper torque limit active Yes No 
 09 Lower torque limit active Yes No 
 11 Speed setpoint limited Yes No 
 13 Encoderless operation due to a fault Yes No 
 19 Reserved Yes No 
Appendix
A.3Parameters
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 739
