r1438 Speed controller speed setpoint
 Data type: FloatingPoint32 Visible in: S
tandard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: U/f control, Speed controller
Unit: rpm
Description: Displays the speed setpoint after setpoint limiting for the P component of the speed controller.
p1441[0] Actual speed smoothing time
 Data type: FloatingPoint32 Visible in: Ext
ended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Operation
Parameter group: Speed controller, Speed actual value 󹪝lter
 Unit
: ms
 Min:
0.00 [ms]
Max:
50.00 [ms]
Factory setting:
0.00 [ms]
Description: Sets the smoothing time constant (PT1) for the speed actual value.
Dependency: See also: r0063
Note
The speed actual value should be smoot
hed for encoders with a low pulse number or for resolvers.
After this parameter has been changed, we recommend that the speed controller is adapted and/or the speed controller
settings checked Kp (p1460) and Tn (p1462).
p1460[0] Speed controller P gain
 Data type: FloatingPoint32 Visible in: Standard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Operation
Parameter group: Speed controller
 Unit: Nms/r
ad
 Min:
0.0000 [Nms/rad]
Max:
5e+08 [Nms/rad]
Fact
ory setting:
0.3000 [Nms/rad]
Description: Sets the P gain of the speed controller.
The drive de
termines the P gain for One Button Tuning and writes the value to p1460.
The value can be changed.
Dependency: See also: p1462
Note
The higher the set P g
ain, the faster and more unstable the control.
