p1670[0] Current setpoint 󹪝lter 3 numerat
or natural frequency
 Data type: FloatingPoint32 Visible in: Extended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Operation
Parameter group: Current setpoint 󹪝lter
 Unit
: Hz
 Min:
0.5 [Hz]
Max:
16000.0 [Hz]
Factory setting:
1999.0 [Hz]
Description: Sets the numerator natural frequency for current setpoint 󹪝lter 3 (gener
al 󹪝lter).
Dependency: Current setpoint 󹪝lter 3 is activat
ed via p1656.2 and parameterized via p1667 ... p1671.
p1671[0] Current setpoint 󹪝lter 3 numerat
or damping
 Data type: FloatingPoint32 Visible in: Ext
ended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Operation
Parameter group: Current setpoint 󹪝lter
 Unit
: -
 Min:
0.000
Max:
10.000
Factory setting:
0.700
Description: Sets the numerator damping for current setpoint 󹪝lter 3.
Dependency: Cur
rent setpoint 󹪝lter 3 is activat
ed via p1656.2 and parameterized via p1667 ... p1671.
p1672[0] Current setpoint 󹪝lter 4 type
 Data type: Integer16 V
isible in: Extended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Operation
Parameter group: Current setpoint 󹪝lter
 Unit
: -
 Min:
1
Max:
2
Factory setting:
1
Description: Sets current setpoint 󹪝lter 4 as lowpas
s 󹪝lter (PT2) or general 2nd order 󹪝lter.
Value: 1: PT2 low pass
 2: General 2nd order 󹪝lt
er
Dependency: Cur
rent setpoint 󹪝lter 4 is activat
ed via p1656.3 and parameterized via p1672 ... p1676.
p1673[0] Current setpoint 󹪝lter 4 denominator natur
al frequency
 Data type: FloatingPoint32 Visible in: Ext
ended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Operation
Parameter group: Current setpoint 󹪝lter
 Unit
: Hz
Appendix
A.3Parameters
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 753
