Index: [0] = PZD 1 + 2
[1] = PZD 2 + 3
[2] = PZD 3 + 4
[3] = PZD 4 + 5
[4] = PZD 5 + 6
[5] = PZD 6 + 7
[6] = PZD 7 + 8
[7] = PZD 8 + 9
[8] = PZD 9 + 10
[9] = PZD 10 + 11
[10] = PZD 11 + 12
[11] = PZD 12 + 13
[12] = PZD 13 + 14
[13] = PZD 14 + 15
[14] = PZD 15 + 16
[15] = PZD 16 + 17
[16] = PZD 17 + 18
[17] = PZD 18 + 19
[18] = PZD 19 + 20
[19] = PZD 20 + 21
[20] = PZD 21 + 22
[21] = PZD 22 + 23
[22] = PZD 23 + 24
[23] = PZD 24 + 25
[24] = PZD 25 + 26
[25] = PZD 26 + 27
[26] = PZD 27 + 28
Dependency: See also: c2053
NOTICE
A maximum of 4 indices of the "trace" function can be used.
c2104[0] 2nd acknowledge faults
 Data type: Unsigned8 Visible in: Ext
ended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Faults / alarms
Unit: -
Description: Signal 2 to acknowledge faults.
Note
A fault acknow
ledgment is triggered with a 0/1 signal.
c2106[0] External fault 1
 Data type: Unsigned8 Visible in: Ext
ended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Faults / alarms
Unit: -
Description: Signal for external fault 1.
Dependency: See also: F07860
