Note
An external fault is initiat
ed with a 1->0 edge.
If this fault is initiated at the Control Unit, then it is transferred to all of the drive objects available.
r2109[0...63] Fault time removed in milliseconds
 Data type: Unsigned32 Visible in: Ext
ended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Faults / alarms
Unit: ms
Description: Displays the system runtime in milliseconds when the fault was removed.
Dependency: See also: r0945, r0947, r0948, r0949, r2114, r2130, r2133, r2136, r3122
NOTICE
The time comprises r2136 (days) and r2109 (milliseconds).
Note
The bu󹪜er paramet
ers are cyclically updated in the background (refer to status signal in r2139).
The structure of the fault bu󹪜er and the assignment of the indices is shown in r0945.
r2111 Alarm counter
 Data type: Unsigned16 Visible in: Ext
ended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Faults / alarms
Unit: -
Description: Number of alarms that have occurred.
Dependency: See also: r2122, r2123, r2124, r2125
Note
The paramet
er is reset to 0 at POWER ON.
r2114[0...1] System runtime total
 Data type: Unsigned32 Visible in: S
tandard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Diagnostics general
Unit: -
Description: Displays the total system runtime of the converter.
The time comprises r2114[0] (milliseconds) and r2114[1] (days).
After r2114[0] has reached a value of 86.400.000 ms (24 hours) this value is reset and r2114[1] is incremented.
Index: [0] = Milliseconds
[1] = Days
No
te
The counter values ar
e saved when the power supply is switched o󹪜.
After the converter is switched on, the counter continues to run with the last value that was saved.
Appendix
A.3Parameters
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 761
