r2124[0...63] Alarm value
 Data type: Integer32 V
isible in: Extended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Faults / alarms
Unit: -
Description: Displays additional information about the active alarm (as integer number).
Dependency: See also: r2122, r2123, r2125, r2134, r2145, r2146, r3123
Note
The bu󹪜er par
amet
ers are cyclically updated in the background (refer to status signal in r2139).
The structure of the alarm bu󹪜er and the assignment of the indices is shown in r2122.
r2125[0...63] Alarm time removed in milliseconds
 Data type: Unsigned32 Visible in: Ext
ended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Faults / alarms
Unit: ms
Description: Displays the system runtime in milliseconds when the alarm was removed.
Dependency: See also: r2114, r2122, r2123, r2124, r2134, r2145, r2146, r3123
NOTICE
The time comprises r2146 (days) and r2125 (milliseconds).
Note
The bu󹪜er paramet
ers are cyclically updated in the background (refer to status signal in r2139).
The structure of the alarm bu󹪜er and the assignment of the indices is shown in r2122.
r2130[0...63] Fault time received in days
 Data type: Unsigned16 Visible in: Ext
ended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Faults / alarms
Unit: -
Description: Displays the system runtime in days when the fault occurred.
Dependency: See also: r0945, r0947, r0948, r0949, r2109, r2114, r2133, r2136, r3122
NOTICE
The time comprises r2130 (days) and r0948 (milliseconds).
Note
The bu󹪜er paramet
ers are cyclically updated in the background (refer to status signal in r2139).
r2131 Actual fault code
 Data type: Unsigned16 Visible in: Standard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Faults / alarms
Unit: -
Description: Displays the code of the oldest active fault.
Appendix
A.3Parameters
SINAMICS S200 PROFINET servo drive system with SIMOTICS S-1FL2
Operating Instructions, 11/2023, FW V6.3, A5E51646752B AB 763
