c2644 EPOS direct setpoint input/MDI acceleration override
 Data type: FloatingPoint32 Visible in: S
tandard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Direct setpoint input (MDI)
Unit: %
Description: Signal for acceleration override in the operating mode "direct setpoint input/MDI".
Dependency: See also: c2649, c2650, c11560
NOTICE
The parameter may be protected as a result of r0922 and cannot be changed.
Note
Depending on c2649, the acceleration o
verride is either transferred continuously or edge-triggered.
The signal value 4000 hex (16384 dec) corresponds to 100 %.
c2645 EPOS direct setpoint input/MDI deceleration override
 Data type: FloatingPoint32 Visible in: S
tandard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Traversing blocks
Unit: %
Description: Signal for the deceleration override in the operating mode "Direct setpoint input/MDI".
Dependency: See also: c2649, c2650, c11561
NOTICE
If, when calculating the traversing pro󹪝le, it is identi󹪝ed t
hat the target position with the programmed deceleration
override cannot be reached without reversing the direction, then when accepting the dynamic values, the larger
deceleration override is accepted and becomes e󹪜ective.
The parameter may be protected as a result of r0922 and cannot be changed.
Note
Depending on c2649, the deceleration o
verride is either transferred continuously or edge-triggered.
The signal value 4000 hex (16384 dec) corresponds to 100 %.
c2646 EPOS velocity override
 Data type: FloatingPoint32 Visible in: S
tandard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: Jog, Homing, Traversing blocks, Direct setpoint input (MDI)
Unit: %
Description: Signal for the velocity override.
This velocity ov
erride is e󹪜ective in the following operating modes "Direct setpoint input/MDI", "Traversing blocks",
"Jogging" and "Active homing" (when approaching the reference cam).
Dependency: See also: p2571, p2585, p2586, p2605, p2618, c2643, r2681
NOTICE
The parameter may be protected as a result of r0922 and cannot be changed.
Note
The e󹪜ective ov
erride (r2681) can di󹪜er from the speci󹪝ed override due to limits (e.g. maximum velocity).
