r3988 Final boot state
 Data type: Integer16 V
isible in: Extended display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Parameter group: System identi󹪝cation
Unit: -
Description: Displays the 󹪝nal boot st
ates.
001 - Software error
200 - Carry out 󹪝rst commissioning
250 - Topology error (check the connected hardware)
800 - Ready
The following options are available to reach the "Ready" state:
- Check the project and load again.
- Restore factory setting.
- Check the hardware.
- Carry out a POWER ON (switch-o󹪜/switch-on).
p4405 PTO maximum output frequency
S200 PN Data type: FloatingPoint32 Visible in: S
tandard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Commissioning
Parameter group: Pulse encoder emulation
 Unit: kHz
 Min:
1 [kHz]
Max:
5000 [kHz]
Factory setting:
1000 [kHz]
Description: Sets the maximum output frequency for encoder emulation.
NOTICE
The hardware is designed for a maximum PTO output frequency of 4 MHz. To tolerate any overshoot as a result of the
motor contr
ol, p4405 can be set approximately 10 % above 4 MHz.
p4408 PTO pulse number
S200 PN Data type: Unsigned32 Visible in: S
tandard display 
Read permission: Read drive data or acknowledge messages
Write permission: Edit device con󹪝gur
ation or driv
e applications
Can be changed in the operating
stat
e:
Commissioning
Parameter group: Pulse encoder emulation
 Unit: -
 Min:
0
Max:
16777216
Factory setting:
1024
Description: Sets the pulse number output from the PTO.
